CONTRIK CPVT6RD, Power Strip XO, 16A
Power Strip Xtreme Outdoor (XO) is a compact distribution solution for mobile outdoor applications.
Rugged EASYLEN® housing is ideally suited for outdoor usage and demanding applications under harsh conditions.
1x powerCON® TRUE1® TOP (m) In and 6x powerCON® TRUE1® TOP (f) Out.
Features & Benefits:
- Extreme robust and safe EASYLEN® housing with leather grain texture
- Highly reliable NEUTRIK® powerCON® TRUE1® TOP recepticals for In, Out and Daisy chaining
- Flame retardant (UL94-V2) and non-conductive housing material
- High outdoor protection (IP65, IK, ..)
- Light weight, compact and stackable housing design
- Versatile mounting options
Markets & Applications:
-
Markets: Professional video wall, lighting, audio
-
Mobile applications: Festivals, live events
-
Semi-permanent applications: Theaters, studios, fairs
Technical data:
Input device: 1x powerCON® TRUE1® TOP (m) with self-closing caps
Output device: 6x powerCON® TRUE1® TOP (f) with self-closing caps
Daisy chaining: 1x powerCON® TRUE1® TOP with self-closing caps
Electrical protection: Protection class II
Dielectric strength: 0.5kV/mm
Rated voltage: 250VAC
Rated current: 16A (USA: 20A)
Number of electrical contacts: 2 + PE
Phases: Single phase
Lifetime: >5000 mating cycles per connector
Dimensions: 380 x 91.2 x 77mm³
Conductor cross section: 2.08mm²
Weight: 1.15kg
Mounting options: Truss clamp, mounting holes for pegging or suspension
Type of construction: Stackable
Housing material: Easylen®
Standards compatibility: UL94-V2
Housing protection: IP65
Operational temperature range: -25 to +40°C
